Spec Item

Description

CPU Cooler

CPU Cooler

CF-1150SB-R11

CF-1150SC-RS

CF-1150SD-RS

Environment

Humidity

5% ~ 95% non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

PCIe Mini slot

I/O Interface

Audio

Supports by IEI AC-KIT-892HD audio kit

Digital I/O

8-bit Digital I/O

Display

Dual display supported 1 x VGA 1 x iDP interface

Ethernet

LAN1: Intel® I217LM with Intel® AMT 9.0 support

LAN2: Intel® I210-AT PCIe controller

I/O Interface

with NCSI support

I/O Interface

1 x Internal RS-485

4 x Internal USB 2.0

2 x Internal USB 3.0

1 x KB/MS

2 x LAN LED

1 x LPT

1 x Internal RS-422

1 x Internal Display

1 x I²C

2 x Ethernet

2 x USB 3.0

4 x Internal RS-232

Option

iRIS

1 x iRIS-2400 slot

Power

Power consumption

5V@3.55A, 12V@0.37A, Vcore_12V@7.61A, 3.3V@1.55A, 5VSB@0.13A (Intel® E3-1240 v3 3.4GHz CPU with 16GB (4x4GB) 1333MHz DDR3 memory)

Storage

Storage

1 x mSATA (colay SATA port 6) (support SATA 6GB/s signal only) 6 x SATA 6GB/s (RAID 0, 1, 5, 10 supported)

System

Chipset

Intel® C226

CPU

LGA 1150 Intel® Xeon® E3, Core? i3, Pentium® or Celeron® processor supported

CPU Socket

LGA1150

Memory Max.

Four 240-pin 1600/1333MHz dualchannel DDR3 & DDR3L SDRAM unbuffered DIMMs (system max. 32GB)

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
