Spec Item

Description

CPU Cooler

CPU Cooler

CF-1150SB-R11

CF-1150SC-R10

CF-1150SD-R10

Environment

Humidity

5% ~ 95% non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

PCIe Mini slot

I/O Interface

Audio

Supports by IEI AC-KIT-892HD audio kit

Digital I/O

8-bit Digital I/O (4-bit input/4-bit output)

Display

Dual display supported VGA (up to 1920x1200 @ 60 Hz) iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 3840x2160 @60 Hz)

Ethernet

LAN1: Intel® I217LM with Intel® AMT 9.0 support

LAN2: Intel® I210-AT PCIe controller with NCSI support

I/O Interface

I/O Interface

1 x LPT

2 x Internal USB 3.0

4 x Internal USB 2.0

1 x Internal RS-422/485

4 x Internal RS-232

2 x USB 3.0

Option

iRIS

1 x iRIS-2400 slot

Power

Power consumption

5V@3.55A, 12V@0.37A, Vcore_12V@7.61A, 3.3V@1.55A, 5VSB@0.13A (Intel® Core? i7-4770K 3.90 GHz CPU with 16GB (4x4GB) 1333MHz DDR3 memory)

Storage

Storage

1 x mSATA (colay SATA port 6) (support SATA 6GB/s signal only)

6 x SATA 6GB/s (RAID 0, 1, 5, 10 supported)

System

Chipset

Intel® Q87

CPU

Intel® 4th generation Core? i7/i5/i3, Pentium® or Celeron® processor supported

CPU Socket

LGA1150

Memory Max.

Four 240-pin 1600/1333MHz dual-channel DDR3 & DDR3L SDRAM unbuffered DIMMs support up to 32GB

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
