Spec Item

Description

CPU Cooler

CPU Cooler

CF-1150SB-R11

CF-1150SC-R20

CF-1150SE-R10

CF-1150SF-R10

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x PCIe Mini slot (PCIe Mini & mSATA colay) One PCIe x16 & four PCIe x1 signal via golden finger PCI signal by ITE IT 8892 (PCIe to PCI bridge)

/O Interface

Audio

Support 7.1-channel HD Audio by IEI AC-KIT-892HD kit

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Display

Dual independent display VGA (up to 1920x1200@60 Hz) iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 3840x2160@60 Hz)

Ethernet

Dual Realtek RTL8111E PCIe GbE controllers supported

I/O Interface

I/O Interface

2 x Internal RS-232

1 x Internal RS-422/485

4 x Internal USB 2.0

2 x Internal USB 3.0

1 x LPT

2 x USB 2.0

Power

Power consumption

5V@3.41A, 12V@0.35A, Vcore_12V@7.52A, 3.3V@1.41A, 5VSB@0.12A (Intel® Core? i7-4770K 3.90 GHz CPU with 8 GB (two 4 GB) 1333 MHz DDR3 memory)

Storage

Storage

2 x SATA 6Gb/s

2 x SATA 3Gb/s (H81 supports AHCI, no RAID)

System

Chipset

Intel® H81

CPU

4th generation LGA 1150 Intel® Core? i7/i5/i3, Pentium® or Celeron® processor supported

CPU Socket

LGA1150

Memory Max.

Two 240-pin 1600/1333 MHz dual-channel unbuffered DDR3 & DDR3L SDRAM DIMMs support up to 16 GB

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset
