Part Number

USB-4711A-AE

General

Power Consumption

Typical: 5 V @ 360 mA; Max.: 5 V @ 450 mA

OS Support

32-bit/64-bit Windows 7/8/10, and Linux

Dimensions

132 x 80 x 32 mm (5.2" x 3.15" x 1.26")

Bus

USB 2.0

I/O Connectors

Onboard screw terminal

Operating Temperature

0~60 (32~140°F)

Programming Language

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

Analog Input

Sampling Rates(S/s)

150 K

Resolution(Bits)

12

Bipolar Inputs (V)

±10, ±5, ±2.5, ±1.25, ±0.625

Channels

16

Type

Scan

Analog Output

Resolution(Bits)

12

Channels

2

Update Rate(S/s)

Static

TTL DI/O

Input Channels

8

Output Channels

8
