Part Number

PCIE-1730-AE

PCIE-1730H-AE

General

Power Consumption

Typical: 3.3 V @ 280 mA, Max.: 3.3 V @ 420mA

Typical: 3.3 V @ 280 mA, Max.: 3.3 V @ 420mA

OS Support

32-bit/64-bit Windows 7/8/10, and Linux

32-bit/64-bit Windows 7/8/10, and Linux

Dimensions

175 x 100 mm (6.9" x 3.9")

175 x 100 mm (6.9" x 3.9")

Bus

PCIe

PCIe

I/O Connectors

37-pin D-Sub female,20-pin insulation displacement connectors

37-pin D-Sub female,20-pin insulation displacement connectors

Operating Temperature

0 ~ 60°C (32 ~ 140°F)

0 ~ 60°C (32 ~ 140°F)

Programming Language

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

TTL DI/O

Input Channels

16

16

Output Channels

16

16

Isolated Digital I/O

Input Channels

16

16

Input Range

10 ~ 30 VDC

10 ~ 30 VDC

Output Channels

16

16

Output Ranges

5 ~ 40 VDC

5 ~ 40 VDC
