Part Number

IPC-631MB-50RE

IPC-631MB-50ZE

Form Factor

Form Factor

4U Rackmount

4U Rackmount

Cooling

Air Filter

Yes

Yes

Fan

2 (12 cm / 82 CFM)

2 (12 cm / 82 CFM)

Disk Drive Bay

2.5" Internal

2

2

Hot-swap Drive Bay

2 ( 2.5" SATA - Optional )

2 ( 2.5" SATA - Optional )

Slim ODD

1

1

Environment

Non-Operational Temperature

-40 ~ 70° C (-40 ~ 156° F)

-40 ~ 70° C (-40 ~ 156° F)

Operating-Temperature

0 ~ 45

0 ~ 45

Shock

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Non-Operating Humidity

10 ~ 95% @ 60° C, non-condensing

10 ~ 95% @ 60° C, non-condensing

Operating Vibration (5 ~ 500 Hz)

1 Grms

1 Grms

Non-Operating Vibration (5 ~ 500 Hz)

2 G

2 G

Front I/O Interface

Phoenix front PW-ON

1

1

Miscellaneous

Control

Power Switch, System reset

Power Switch, System reset

LED Indicators

Power, HDD

Power, HDD

System Monitoring

System Monitoring

Chassis intrusion switch

Chassis intrusion switch

Physical Characteristics

Weight

8 kg (17.6 lb)

9.96 kg (21.93 lb)

Dimensions (W x H x D)

482 x 177 x 348 mm (19'' x 7.0'' x 13.7'')

482 x 177 x 348 mm (19'' x 7.0'' x 13.7'')

Power Supply

Power Supply

500W (Redundant)

500W (Redundant)
