Part Number |
HPC-7282-00A1E |
Drive Bay |
|
Hot Swap External |
8 (3.5") Lockable |
Internal 3.5" |
2 |
Slim Optical Drive External |
1 |
Environment |
|
Non-Operating Humidity |
10 ~ 95% @ 40° C, non-condensing |
Non-Operating Vibration (5 ~ 500 Hz) |
0.5 Grms |
Non-Operational Temperature |
-40 ~ 70° C (-40 ~ 158° F) |
Operating Humidity |
10 ~ 85% @ 40° C, non-condensing |
Vibration (5 ~ 500 Hz) |
0.25 Grms |
Operating Temperature |
0 ~ 40° C (32 ~ 104° F) |
Front I/O Interface |
|
COM Port |
1 |
USB2.0 |
10 D-sub openings supporting up to 10 COMs with optinal COM cables |
Miscellaneous |
|
LED Indicators |
Power, HDD, LAN1, LAN2, System Information |
Physical Characteristics |
|
Dimensions (W x H x D) |
437 x 88.9 x 533.4 mm (17.2" x 3.5" x 21") |
Cooling |
|
System Fan |
3 x 80 mm Fan Module with swappable bracket |
