Part Number

IPC-6806-25DE

IPC-6806S-25CE

IPC-6806W-35CE

Form Factor

CPU Card Form Factor

Full-Sized

Full-Sized

Full-Sized

Front I/O Interface

USB2.0

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

Cooling

Air Filter

Yes

Yes

Yes

Fan

1 (9cm / 53 CFM)

1 (9cm / 53 CFM)

1 (9cm / 53 CFM)

Environment

Operating-Temperature

0 ~ 45

0 ~ 45

0 ~ 45

Non-Operational Temperature

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

Non-Operating Vibration

2 G

2 G

2 G

Operating Humidity

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

Non-Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Vibration (5 ~ 500 Hz)

0.5 Grms

0.5 Grms

0.5 Grms

Physical Characteristics

Weight

6.3 kg (13.9 lb)

5.6 kg (12.3 lb)

8 kg (17.6 lb)

Dimensions (W x H x D)

166 x 178 x 398 mm

191 x 178 x 290 mm

198 x 221 x 398 mm

Miscellaneous

LED Indicators

Power, HDD

Power, HDD

Power, HDD

Control

Power Switch, System reset

Power Switch, System reset

Power Switch, System reset

Drive Bay

External 3.5"

1

1

1

Internal 3.5"

1

1

1

Power Supply

Power Supply

250W (Single)

250W (Single)

350W (Single)
