Part Number |
IPC-6806S-25DE |
Form Factor |
|
CPU Card Form Factor |
Half-sized |
Front I/O Interface |
|
USB2.0 |
10 D-sub openings supporting up to 10 COMs with optinal COM cables |
Cooling |
|
Air Filter |
Yes |
Fan |
1 (9cm / 53 CFM) |
Environment |
|
Operating-Temperature |
0 ~ 45 |
Non-Operational Temperature |
-20 ~ 60° C (-4 ~ 140° F) |
Non-Operating Vibration |
2 G |
Operating Humidity |
10 ~ 85% @ 40° C, non-condensing |
Non-Operating Humidity |
10 ~ 95% @ 40° C, non-condensing |
Vibration (5 ~ 500 Hz) |
0.5 Grms |
Physical Characteristics |
|
Weight |
5.6 kg (12.3 lb) |
Dimensions (W x H x D) |
191 x 178 x 290 mm |
Miscellaneous |
|
LED Indicators |
Power, HDD |
Control |
Power Switch, System reset |
Drive Bay |
|
External 3.5" |
1 and 1 2.5" hot swap tray |
Internal 3.5" |
1 |
