Part Number

IPC-510BP-00XBE

IPC-510MB-00XBE

IPC-510MB-00XCE

IPC-510MB-30CE

IPC-510MB-30ZCE

IPC-510MB-40CE

IPC-510MB-40ZCE

IPC-510BP-00XCE

IPC-510BP-30CE

IPC-510BP-30ZCE

IPC-510BP-40ZCE

Form Factor

Form Factor

Form Factor

Form Factor

Form Factor

Form Factor

Form Factor

Form Factor

Form Factor

Form Factor

Form Factor

Form Factor

Front I/O Interface

USB2.0

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

PS/2

1

1

1

1

1

1

1

1

1

1

1

Cooling

System Fan

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

1 (12 cm / 77 CFM)

Environment

Operating-Temperature

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

Non-Operational Temperature

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

Operating Shock

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

Operating Humidity

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

Non-Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Operating Vibration (5 ~ 500 Hz)

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

Non-Operating Vibration (5 ~ 500 Hz)

2 G

2 G

2 G

2 G

2 G

2 G

2 G

2 G

2 G

2 G

2 G

Physical Characteristics

Weight

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

10.7 kg (23.5 lb)

Dimensions (W x H x D)

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

481 x 175 x 446 mm ( 19" x 7" x 17.6" )

Disk Drive Bay

5.25 External Bay

3

3

3

3

3

3

3

3

3

3

3

3.5 External Bay

1

1

1

1

1

1

1

1

1

1

1

3.5 Internal Bay

1

1

1

1

1

1

1

1

1

1

1

Miscellaneous

LED Indicators

Power, HDD activity

Power, HDD activity

Power, HDD activity

Power, HDD activity

Power, HDD activity

-

-

Power, HDD activity

Power, HDD activity

-

-

Rear Panel

Two 9-pin D-Sub openings

One 9-pin D-Sub and one 68-pin SCSI opening

One 9-pin D-Sub and one 68-pin SCSI opening

One 9-pin D-Sub and one 68-pin SCSI opening

Five 9-pin D-Sub & one 68-pin SCSI openings

One 9-pin D-Sub and one 68-pin SCSI opening

One 9-pin D-Sub and one 68-pin SCSI opening

Two 9-pin D-Sub openings

Two 9-pin D-Sub openings

Two 9-pin D-Sub openings

Two 9-pin D-Sub openings

Power Supply

Power Supply

-

-

-

-

-

-

-

-

-

-

-
