IPC-611
支持ATX 母板或 多達15槽的PICMG無源底板
抗沖擊磁盤驅動器托架可支持3個5.25" 和1個3.5"磁盤驅動器
獨特的固定壓條設計帶有橡膠墊腳，可以防止卡受到?jīng)_擊或振動造成的損壞
電源和HDD活動性通知，改善系統性能
前部可訪問空氣過濾器，方便系統維護
可鎖前門，防止未經許可的訪問
靈活的機械設計，支持300 W單PS/2和冗余ATX電源
規格

Part Number

IPC-611BP-00XBE

IPC-611MB-00XBE

Form Factor

Form Factor

4U Rackmount

4U Rackmount

4U Rackmount

Front I/O Interface

USB2.0

10 D-sub openings supporting up to 10 COMs with optinal COM cables

10 D-sub openings supporting up to 10 COMs with optinal COM cables

Cooling

Air Filter

Yes

Yes

Fan

1 (12 cm / 85 CFM)

1 (12 cm / 85 CFM)

Environment

Operating-Temperature

0 ~ 45

0 ~ 45

Non-Operational Temperature

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

Operating Shock

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

Operating Humidity

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

Non-Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Operating Vibration (5 ~ 500 Hz)

1 Grms

1 Grms

Non-Operating Vibration (5 ~ 500 Hz)

2 G

2 G

Physical Characteristics

Weight

14.2 kg (31.2 lb)

14.2 kg (31.2 lb)

Dimensions (W x H x D)

482 x 177 x 479 mm (19" x 7" x 18.9")

482 x 177 x 479 mm (19" x 7" x 18.9")

Disk Drive Bay

5.25 External Bay

3

3

3.5" External Bay

1

1

Miscellaneous

LED Indicators

Power, HDD activity

Power, HDD activity

Graphics

Controller

Power, System reset button

Power, System reset button
