AIIS-1240
支持英特爾酷睿? i7/i5/i3 CPU(LGA1155)
4個以太網供電PoE,符合IEEE 802.3af 規范
受電設備自動檢測與分類
支持IEEE 1588 & 千兆位以太網視覺設備
兼容千兆位以太網攝像機
緊湊&貼心設計
體積小于3升
隔離數字I/O
內部1個USB加鎖特別設計(最大49mm)
墻壁或DIN導軌安裝套件（可選）
簡單的風扇濾網維護
內建重力傳感器進行振動檢測
規格

Part Number

AIIS-1240-00A1E

Processor System

CPU

Intel Core i3/i5/i7 (LGA1155)

Frequency

Up to 3.4 GHz

Core Number

2/4/4

L3 Cache

3 / 6 / 8 MB

BIOS

AMI 64 Mb SPI Flash

Chipset

Intel H61

Memory

Technology

Dual Channel DDR3 1066/1333 MHz (Non ECC)

Socket

2 x 204-pin SODIMM

Max. Capacity

16 GB (8 GB per DIMM)

Ethernet

Controller

LAN1: Intel 82579V LAN2: Intel 82583V

WatchDog Timer

Output

System Reset

Interval

Programmable 1 ~ 255 sec/min

Storage

CFast

1

HDD

1 x internal 2.5" HDD Bay

Front I/O Interface

USB3.0

4

Rear I/O Interface

USB2.0

4

Cooling

System Fan

1 (6cm / 27.7 CFM)

Environment

Operating-Temperature

0 ~ 45° C

Operating Vibration

1Grms, random, 5~500Hz, 3 axes, 1 hr/axis

Operating Shock

10G, half sine wave, 11 ms duration

Physical Characteristics

Weight

2.5 kg

Dimensions (W x H x D)

232 x 70 x 175 mm (9.06" x 2.76" x 6.89")

Miscellaneous

LED Indicators

Power, HDD, temperature

Control

Power on/off switch

Graphics

Chipset Integrated

Integrated Intel HD Graphics
