Part Number

EKI-9628G-4CI-AE

Product Category

Layer 3 - Managed

Yes

Interface (...)

Ports Number

28

General (X)

Ethernet Connectors

24 x RJ-45 + 4 x RJ45/SFP Combo ports

I/O (X)

Transmission Speed

10/100/1000Base-T(X)

Power Supply (X)

Power Input

12 ~ 48 VDC

Operating System (X)

Temperature (Operating)

-40 ~ 75°C (-40 ~ 167°F)

Communication (XX)

IEEE Standard

802.3u, 802.3ab,802.3z, 802.3ad, 802.3x ,802.1X,802.1D, 802.1s,802.1w,802.1Q,802.1ab

* Port Configuration

Ethernet Port Description

10 x 10/100/1000Base-T(X)

Ethernet Transmission Distance (X)

100 m

Ethernet PoE Port Number

-

Fiber Port Interface (X)

SFP

Fiber Port Description

4 x SFP(mini-GBIC) ports

Fiber Transmission Distance (X)

Up to 110km

Switch Properties

MAC Table Size

8K

Packet Buffer Size

4.1M bit

Switch Fabric Speed

56Gbps

Jumbo Frame

9,216 bytes

Mechanism

Dimensions (W x H x D)

438 x 43.6 x 259.2 mm

IP Rating

IP30

Enclosure

Metal shell

Weight

3.8kg

Mounting (X)

1U 19" Rack mount

Environment

Operating Temperature (X)

-40 ~ 70°C (40~158°F)

Storage Temperature (X)

-40 ~ 85°C (-40 ~ 185°F)

Relative Humidity (Non-condensing)

10 ~ 95%

Power Requirement (X)

Operating Voltage

12 ~ 48 VDC

Operating Current

8.3A @ 24V

Power Consumption

20 W

Connectors

4-pin removable screw terminal (power & relay)

Reverse Polarity

Present

Certification

EMI

CE, FCC Class A

Safety

UL 61010

EMC

EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3)

Shock

IEC 60068-2-27

Freefall

IEC 60068-2-32

Vibration

IEC 60068-2-6

Warranty

Warranty Period

5 years
