Part Number |
FPM-5151G-R3BE |
Display |
|
Viewing Angle (H/V°) |
160/140 |
Luminance (cd/m2) |
400 |
Max. Resolution |
1024 x 768 |
Max. Colors |
16.7 M |
Display Type |
15" XGA |
Display Size |
15" |
Backlight MTBF(hrs) |
50000 |
General |
|
Certifications |
BSMI, CCC, CE, FCC Class A, UL |
Weight (Net) |
6kg |
Dimensions |
449.92 x 315.63 x 50.5 mm |
Video Port |
VGA/DVI |
Power Input Voltage |
10-30v |
OSD(onscreen display) |
On rear side with lockable function |
Operating System |
Windows XP, Vista,7, 8,10,XPe and Linux |
Environment |
|
Operating Temperature |
0 ~ 50°C (32 ~ 122°F) |
Storage Temperature |
-20 ~ 60°C (-4 ~ 140°F) |
Touchscreen |
|
Lifespan |
10 million with a silicone rubber of R8 finger, writing rate is by 250g at 2 times/s |
Light Transmission |
Above 80% |
Resolution |
Linearity |
Interface |
RS-232 and USB |
OS Support |
Windows XP, Vista,7, 8,10,XPe and Linux |
Power Consumption |
+5 V @ 100 mA |
Type |
5-wire, analog resistive |
