Part Number |
FPM-3191G-R3BE |
General |
|
Certifications |
BSMI, CCC, CE, FCC Class A, UL |
Weight (Net) |
10.65kg |
Dimensions |
482mm x 399.2mm x 67 mm (18.98" x 15.71" x 2.64") |
Video Port |
VGA & DVI |
Power Input Voltage |
12v & 24v |
OSD(onscreen display) |
On rear side with lockable function |
Operating System |
Windows XP, Vista,7, 8,10,XPe and Linux |
LCD Display |
|
Viewing Angle (H/V°) |
170/160 |
Luminance (cd/m2) |
350 |
Contrast Ratio |
1000:1 |
Max. Resolution |
1280x1024 |
Max. Colors |
16.7M |
Display Type |
SXGA TFT LCD with LED backlight |
Display Size |
19" |
Backlight Lifetime |
50, 000 hrs |
Environment |
|
Operating Temperature |
-20 ~ 60°C (-4 ~ 140°F) |
Storage Temperature |
-30 ~ 80°C (-22 ~ 176°F) |
Touchscreen |
|
Lifespan |
35 million touches at a single point |
Light Transmission |
80% ±5 |
Resolution |
Linearity |
Interface |
RS-232 and USB |
OS Support |
Windows XP, Vista,7, 8,10,XPe and Linux |
Power Consumption |
+5 V @ 100 mA |
