Part Number |
FPM-2120G-R3BE |
Display |
|
Viewing Angle (H/V°) |
160°(V),140°(H) |
Backlight Life (hrs) |
50,000 hrs |
Luminance (cd/m2) |
600 |
Max. Resolution |
1024 x 768 |
Max. Colors |
16.2 M |
Display Type |
XGA TFT LCD with LED backlight |
Display Size |
12.1" |
General |
|
Power Input |
External 60 W power adapter, with AC 100 V ~ 240 V input and DC +12 V @ 5 A output (included) |
Mounting |
Panel, wall, desktop, VESA arm |
Certifications |
BSMI, CCC, CE, FCC, UL |
Enclosure |
Front panel: Aluminum, Rear cover: SECC chassis |
Weight (Net) |
4kg (8.82 lbs) |
Dimensions |
311 x 237 x 40.63 mm (12.24" x 9.33" x 1.60") |
Video Port |
VGA |
Environment |
|
Waterproof |
Front Panel IP65 Compliant |
Operating Temperature |
0 ~ 50°C (32 ~ 122°F) |
Storage Temperature |
-20 ~ 60°C (-4 ~ 140°F) |
Storage Humidity |
10 ~ 95% non-condensing |
Vibration |
5 ~ 500 Hz, 1 Grms (Operating, Random) |
Touchscreen |
|
Lifespan |
36 millions times with a silicone rubber of R8 finger, hitting rate is calculated as being 250g at 2 times per second |
Interface |
RS-232 and USB |
OS Support |
Windows® XP, Vista, 7, 8, 10, XPe, CE and Linux |
