TPC-651T
工業級5.7寸 VGA TFT 液晶屏，50,000小時LED背光壽命
Intel? Atom? E3827 1.75 GHz 雙核處理器，4GB DDR3L 內存
-20~60°C寬溫操作
全平面五線電阻觸摸屏，鋁合金前面板防護等級IP66
彩色LED指示燈顯示操作狀態
支持全尺寸Mini PCIe擴展
創新iDoor技術，支持多種功能擴展（需要選購配件）
緊湊型嵌入式無風扇系統，地板接地保護
支持直流/交流電壓輸入（根據電源適配器選擇）
支持研華SNMP代理
支持研華SusiAccess遠程設備管理軟件
規格

Part Number

TPC-651T-6E3AE

TPC-651T-E3AE

Display

Type

VGA TFT LED LCD

VGA TFT LED LCD

Viewing Angle (H/V°)

160/140

160/140

Backlight Life (hrs)

50, 000 hrs

50, 000 hrs

Luminance (cd/m2)

800

800

Size

6.5"

6.5"

Max. Resolution

640 x 480

640 x 480

Max. Colors

262 K

262 K

Contrast Ratio

600:1

800:1

General

Power Consumption

19.2 W (typical)

19.2 W (typical)

Power Input

24VDC +/- 20%

24VDC +/- 20%

Watchdog Timer

1 ~ 255 sec (system)

1 ~ 255 sec (system)

Mounting

Desktop, Wall, Panel Mount, and VESA or stand mount (with optional kit)

Desktop, Wall, Panel Mount, and VESA or stand mount (with optional kit)

Certifications

BSMI, CCC, CE, FCC Class A, UL, EAC

BSMI, CCC, CE, FCC Class A, UL, EAC

BIOS

AMI UEFI

AMI UEFI

Cooling System

Fanless design

Fanless design

Enclosure

Front bezel: Die-cast Aluminum alloy, Back housing: SECC

Front bezel: Die-cast Aluminum alloy, Back housing: SECC

OS Support

Microsoft® WES7 32bit/64bit / WE8S 64bit / Windows 7/ 8.1 32bit/64bit / Windows 10 Enterprise LTSB

Microsoft® WES7 32bit/64bit / WE8S 64bit / Windows 7/ 8.1 32bit/64bit / Windows 10 Enterprise LTSB

Weight (Net)

1.5 kg

1.5 kg

Dimensions

199 x 152 x 58.9 mm (7.83” x 5.98” x 2.32”)

199 x 152 x 58.9 mm (7.83” x 5.98” x 2.32”)

System Hardware

CPU

Intel® Atom? E3827 1.75 GHz Processor

Intel® Atom? E3827 1.75 GHz Processor

Memory

1 x SO-DIMM with 4GB DDR3L SDRAM (supports up to 8G)

1 x SO-DIMM with 4GB DDR3L SDRAM (supports up to 8G)

Storage

CFast slot x 1, 2.5" SATA SSD slot x 1 (optional)

CFast slot x 1, 2.5" SATA SSD slot x 1 (optional)

LAN

10/100/1000Base-T x 2

10/100/1000Base-T x 2

Expansion Slots

Full-size Mini PCI-E

Full-size Mini PCI-E

I/O

RS-232 x 1, RS-232/422/485 x 1, USB3.0 x 1, USB2.0 x 1

RS-232 x 1, RS-232/422/485 x 1, USB3.0 x 1, USB2.0 x 1

Environment

Ingress Protection

Front panel: IP66

Front panel: IP66

Vibration Protection

With CFast: 2 Grms (5~500 Hz), With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)

With CFast: 2 Grms (5~500 Hz), With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)

Operating Temperature

-20 ~ 60°C (-4 ~ 140°F)

-20 ~ 60°C (-4 ~ 140°F)

Storage Temperature

-30 ~ 70°C (-22 ~ 158°F)

-30 ~ 70°C (-22 ~ 158°F)

Humidity

10 ~ 90% RH @ 40°C, non-condensing

10 ~ 90% RH @ 40°C, non-condensing

Touchscreen

Lifespan

36 million touches at single point

36 million touches at single point

Light Transmission

Above 75%

Above 75%

Resolution

Linearity

Linearity

Type

5-wire, analog resistive

5-wire, analog resistive
