Part Number

PPC-3210SW-PAE

Processor System

CPU

Intel® Celeron® N2930, Quad core

Frequency

1.83 GHz

2nd Cache Memory

2MB

Memory

1 x SO-DIMM, DDR3L 1333, Max 8 GB

Storage 1

1 x 2.5" SATA Bay (Optional, need ordering bracket module for installation);1 x mSATA Bay (default)

Network (LAN)

1 x 10/100/1000Mbps Ethernet

I/O Ports

2 x Serial ports: 1 x RS-232, 1x RS-232/422/485 (Adjustable through BIOS) ;1 x USB 2.0, 1 x USB 3.0

Expansion Slots

1 x Full size Mini PCIe slot

Watchdog Timer

255 timer levels; setup by software

Physical Characteristics

Dimensions

558.4 x 349.8 x 56.2 (219.8" x 137.7" x 22.1")

Weight

7.5 Kg

OS Support

OS Support

Microsoft® Windows 7 32bit&64bit/Windows 8.1 32bit&64bit/Windows 10 32bit&64bit/WES7/WEC 7/Linux/ Android 4.4

Power Supply

Input Voltage

12-24 VDC

Power Consumption

25W (Burn-in test 7.0 in Windows 7 32 bit)

LCD Display

Display Type

21.5" TFT LCD (LED Backlight)

Viewing Angle (H/V°)

89 (left), 89 (right), 89 (up), 89 (down)

Max. Resolution

1920 x 1080

Luminance (cd/m2)

300

Contrast Ratio

208.3340277778

Backlight Life

50, 000 hrs

Touchscreen

Touch Type

Projected capacitive multi-touch 10 points

Light Transmission

90% ± 3%

Controller

USB interface

Environment

Operating Temperature

0 ~ 50°C (32 ~ 122°F) with SSD;0 ~ 40°C (32 ~ 104°F) with HDD (HDD test condition:the SPEC of HDD temperature need more than or equal to 65°C)

Storage Temperature

-40 ~ 60°C (-40~140°F)

Relative Humidity

10 ~ 95% @ 40° C (non-condensing)

Shock

Operating 10 G peak acceleration (11 ms duration), follows IEC 60068-2-27

Vibration

Operating Random Vibration Test 5~500Hz, 1Grms @with HDD, follow IEC 60068-2-64

EMC

CE, FCC Class B, BSMI

Safety

CB, CCC, BSMI, UL

Front Panel Protection

IP65 Compliant
