Part Number

PPC-3120-RE9A

Processor System

CPU

Intel® Atom? E3940 quad core

2nd Cache Memory

2MB

Frequency

1.6 GHz

Memory

1 x SODIMM DDR3L 1866 MHz (max. 8 GB)

Storage

1 x 2.5" SATA Bay, 1 x mSATA Bay

Network (LAN)

2 x 10/100/1000 Mbps Ethernet (Intel I210)

I/O Ports

5 x Serial ports: 4 x RS-232, 1 x isolated RS-422/485 (Adjustable through BIOS) ;4 x USB 3.0;1 x Line-out, 1 x Mic-in;1 x VGA;1 x HDMI;1 x GPIO (8 channels, TTL level, internal)

Expansion Slots

1 x Mini PCIe;Optional: 1 x PCIe x1 or 1 x PCI

Speaker

2 x 1W

Watchdog Timer

Watchdog Timer

255 timer levels, set up by software

Physical Characteristics

Dimensions

317 x 246 x 60.5 mm (12.4 x 9.7 x 2.4 in)

Weight

3.4KG

Power Supply

Input Voltage

9 - 32 Vdc

Power Consumption

32W

OS Support

OS Support

Microsoft® Windows 10 IoT Enterprise, Linux, Android 6.0 Marshmallow

Display

Display Type

12.1" TFT LCD (LED Backlight)

Max. Resolution

1024 x 768

Viewing Angle

80 (left), 80 (right), 70 (up), 70 (down)

Luminance (cd/m2)

600

Contrast Ratio

29.1673611111

Backlight Life (hrs)

50,000 hrs (typical)

Touchscreen

Touch Type

Analog Resistive 5-wire

Light Transmission

80±5% at 550 nm wavelength

Controller

USB interface

Durability (Touches)

Greater than 35 million touches in one location without failure

Environment

Operating Temperature

0 ~ 50° C (32 ~ 122° F)

Storage Temperature

-40 ~ 60°C (-40~140°F)

Relative Humidity

10 ~ 95% @ 40° C (non-condensing)

Shock Protection

Operating 10 G peak acceleration (11 ms duration), follow IEC 60068-2-27

Vibration Protection

Operating Random Vibration Test 5~500Hz, 1Grms @with HDD, follow IEC 60068-2-64

EMC

CE, FCC Class B, BSMI

Safety

CB, CCC, BSMI, UL

Front Panel Protection

IP65 Compliant
