Part Number

UNO-2184G-D45E

UNO-2184G-D64E

General

Mounting

Stand, Wall, VESA (Optional)

Stand, Wall, VESA (Optional)

Power Consumption

40W(Typical), 101W(Maximum)

40W(Typical), 101W(Maximum)

Certifications

CE, UL, CCC, FCC, C-Tick, BSMI

CE, UL, CCC, FCC, C-Tick, BSMI

Weight

3.0 kg

3.0 kg

OS Support

Windows XP/7, WES7, WES-2009, Linux

Windows XP/7, WES7, WES-2009, Linux

Power Input

9 ~ 36 VDC

9 ~ 36 VDC

System Design

Fanless with no internal cabling (except COM3/COM4)

Fanless with no internal cabling (except COM3/COM4)

Enclosure Housing

Aluminum

Aluminum

Dimensions

255 x 152 x 69 mm(10" x 6.0" x 2.7")

255 x 152 x 69 mm(10" x 6.0" x 2.7")

System Hardware

CPU

Intel Core i7-2655LE 2.2 GHz

Intel Core i7-3555LE 2.5GHz

Memory

Built-in 4/8GB DDR3 SO-DIMM

Built-in 4/8GB DDR3 SO-DIMM

Storage

CF: 1 x CFast slot, HDD: One built-in 2.5" SATA HDD bracket(Optional 2 x HDD Bracket Kit)

CF: 1 x CFast slot, HDD: One built-in 2.5" SATA HDD bracket(Optional 2 x HDD Bracket Kit)

Keyboard/Mouse Ports

1 x PS/2

1 x PS/2

Audio

Mic in, Line in, Line out

Mic in, Line in, Line out

Display

1 x DVI-I, 1 x HDMI, 1 x DP (2 x independent displays)

1 x DVI-I, 1 x HDMI, 1 x DP (2 x independent displays)

Mini PCIe Expansion

2 x Mini PCIe slots with 1 x SIM card

2 x Mini PCIe slots with 1 x SIM card

Indicators

LEDs for Power, battery, LAN (Active, Status) and COM (Tx, Rx)

LEDs for Power, battery, LAN (Active, Status) and COM (Tx, Rx)

Watchdog Timer

Programmable 255 levels timer interval, from 1 to 255 sec

Programmable 255 levels timer interval, from 1 to 255 sec

I/O Interface

Serial Ports

2 x RS-232, 2 x RS-232/422/485 with DB9 connectors Automatic RS-485 data flow control

2 x RS-232, 2 x RS-232/422/485 with DB9 connectors Automatic RS-485 data flow control

LAN

4 x 10/100/1000Base-T RJ-45 ports, Supports AMT (UNO-2184G only), wake on LAN and built-in boot ROM in flash BIOS

4 x 10/100/1000Base-T RJ-45 ports, Supports AMT (UNO-2184G only), wake on LAN and built-in boot ROM in flash BIOS

USB

6 x USB (only UNO-2184G-D64E supports 2 x USB3.0)

6 x USB (only UNO-2184G-D64E supports 2 x USB3.0)

Environment

Temperature (Operating)

-10 ~ 60°C (14 ~ 140°F) @ 5 ~ 85% RH. (with air flow)

-10 ~ 60°C (14 ~ 140°F) @ 5 ~ 85% RH. (with air flow)

Temperature (Storage)

-40 ~ 60°C (-40~140°F)

-40 ~ 60°C (-40~140°F)

Humidity (Operating)

95% @ 40°C (non-condensing)

95% @ 40°C (non-condensing)

Vibration Protection

IEC 60068-2-64 (Random 1 Oct./min, 1hr/axis.) HDD: 1 Grms @ 5 ~ 500 Hz

IEC 60068-2-64 (Random 1 Oct./min, 1hr/axis.) HDD: 1 Grms @ 5 ~ 500 Hz

Shock Protection

IEC 60068-2-27, CompactFlash: 50 G @ wall mount, half sine, 11 ms, HDD: 20 G @ wall mount, half sine, 11 ms

IEC 60068-2-27, CompactFlash: 50 G @ wall mount, half sine, 11 ms, HDD: 20 G @ wall mount, half sine, 11 ms

Operating Temperature

-10 ~ 60°C (14 ~ 140°F) @ 5 ~ 85% RH. (with air flow)

-10 ~ 60°C (14 ~ 140°F) @ 5 ~ 85% RH. (with air flow)
