Part Number

UNO-2272G-J2AE

UNO-2272G-N2AE

General

Mounting

Stand, Wall, VESA (Optional), Din-rail (Optional)

Stand, Wall, VESA (Optional), Din-rail (Optional)

Power Consumption

14W (Typical), 45.3W (Max)

14W (Typical), 45.3W (Max)

Certifications

CE, FCC, UL, CCC, BSMI

CE, FCC, UL, CCC, BSMI

Enclosure

Aluminum Housing

Aluminum Housing

Weight (Net)

0.8 kg (1.76 lbs)

0.8 kg (1.76 lbs)

OS Support

Microsoft® Windows 7, Windows 10, Advantech Linux

Microsoft® Windows 7, Advantech Linux

Power Requirement

24VDC ± 20%

24VDC ± 20%

Form factor

Palm Size

Palm Size

Dimensions ( W x D x H )

157 x 88 x 50mm (6.2"x 3.5"x 2.0")

157 x 88 x 50mm (6.2"x 3.5"x 2.0")

System Hardware

Memory

Built-in 2GB DDR3L 1333 MHz up to 8GB

Built-in 2GB DDR3 1600 MHz

Storage

1 x half-size mSATA

1 x half-size mSATA

Watchdog Timer

Programmable 256 levels timer interval, from 1 to 255

Programmable 256 levels timer interval, from 1 to 255

Expansion

2 Full-size mPCIe

2 Full-size mPCIe

Processor

Intel Celeron Quad Core J1900 2.0 GHz

Intel Atom Dual Core N2800 1.86GHz

BIOS

AMI EFI64 Mbit

AMI EFI64 Mbit

System Chip

Intel Atom SoC integrated

Intel Atom SoC integrated

Graphics Engine

Intel® HD Graphics

Intel® HD Graphics

Ethernet

Intel® i210-IT GbE, 802.1Qav, IEEE1588/802.1AS, 802.3az

Intel® i210-IT GbE, 802.1Qav, IEEE1588/802.1AS, 802.3az

LED Indicators

LEDs for Power, HDD, LAN (Active,Status)

LEDs for Power, HDD, LAN (Active,Status)

I/O Interface

Serial Ports

1 x RS-232 (RS-422/485 by BIOS option), DB9, 50~115.2kbps

1 x RS-232, DB9, 50~115.2kbps

Audio

Line-out

Line-out

USB Port

2 x USB 2.0 and 1 x USB 3.0

3 x USB 2.0 Ports

Displays

1 x HDMI, supports 1920 x 1080 @ 60Hz

1 x HDMI, supports 1920 x 1080 @ 60Hz

Power Connector

1x 2 Pins, Terminal Block

1x 2 Pins, Terminal Block

LAN Ports

1 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

1 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

Environment

Relative Humidity

10 ~ 95% @ 40°C non-condensing

10 ~ 95% @ 40°C non-condensing

Ingress Protection

IP40

IP40

Vibration Protection

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA)

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA)

Shock Protection

Operating, IEC 60068-2-27, 50G, half sine, 11ms

Operating, IEC 60068-2-27, 50G, half sine, 11ms

Operating Temperature

-10 ~ 55°C (14~131) @ 5 ~ 85% RH with 0.7 m/s airflow

-10 ~ 55°C (14~131) @ 5 ~ 85% RH with 0.7 m/s airflow

Storage Temperature

-40 ~ 85°C ( -40 ~ 185°F)

-40 ~ 85°C ( -40 ~ 185°F)
