Part Number

UNO-2362G-T2AE

General

Mounting

Stand, Wall, VESA (Optional), Din-rail (Optional)

Power Consumption

14W (Typical), 47.3W (Max)

Certifications

CE, UL, CCC, FCC, BSMI

Enclosure

Aluminum Housing

OS Support

Microsoft® Windows XP/7/ WES7 Linux Fedora

Weight (Net)

1.0kg (2.2lbs)

Power Requirement

24VDC ±15%

Dimensions

190 x 107 x 47 mm (7.5" x 4.2" x 1.8")

Form factor

Small Size

System Hardware

Memory

On-board 2GB DDR3 1066 MHz

Watchdog Timer

Programmable 255 levels timer interval, from 1 to 255 sec

Expansion

1 x Full-size mPCIe slot, mPCIe 2.0 (supports SIM card)

Storage

One mSATA drive One drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), Note: iDoor technology isn't compatible with HDD storage

BIOS

AMI UEFI 32Mbit Flash BIOS

Processor

AMD® G-series T40E 1.0GHz dual core

System Chip

AMD® A50M FCH

Graphics Engine

AMD Radeon? HD 6250 DirectX® 11 graphics with UVD 3.0 2D/3D Accelerator

Ethernet

Realtek RTL8111E, Marvell 88E6172 Giga Ethernet switch with daisy chain technology

LED Indicators

LEDs for Power, battery, LAN (Active, Status) and HDD, 1 x mSATA

I/O Interface

Serial Ports

1x RS-232, DB9, 50~115.2kbps, 1x RS-485, DB9, auto flow control, 50~115.2kbps

LAN

2x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

USB Port

4x USB 2.0 Compliant

Displays

1 x DisplayPort 1.1, supports 1920 x 1080 @ 60Hz; 1 x HDMI v1.3, supports 1920 x 1080 @ 60Hz

Power Connector

1x 2 Pins, Terminal Block

Grounding Protection

Chassis Grounding

Environment

Temperature (Operating)

-10 ~ 60°C (14 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow

Temperature (Storage)

-40 ~ 85°C (-40 ~ 185°F)

Relative Humidity

10 ~ 95% @ 40°C non-condensing

Ingress Protection

IP40

Vibration Protection

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA), Operating, IEC 60068-2-64, 0.75Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Shock Protection

Operating, IEC 60068-2-27, 50G, half sine, 11ms
