Part Number

UNO-2473G-E3AE

UNO-2473G-J3AE

General

Certifications

CCC, CE, FCC, UL, BSMI

CCC, CE, FCC, UL, BSMI

Enclosure

Aluminum Housing

Aluminum Housing

Mounting

Stand, Wall, VESA (Optional), Din-rail (Optional)

Stand, Wall, VESA (Optional), Din-rail (Optional)

OS Support

Microsoft Windows 7, Windows 8

Microsoft® Windows 7, Windows 10, Advantech Linux

Power Requirement

24VDC ± 20%

24VDC ± 20%

Form factor

Regular Size

Regular Size

Dimensions ( W x D x H )

252 x 149 x 62 mm (9.9" x 5.9" x 2.4")

252 x 149 x 62 mm (9.9" x 5.9" x 2.4")

System Hardware

System Chip

Intel Atom SoC integrated

Integrated Intel SoC Chipset

Memory

On-board 4GB DDR3L 1600 MHz

On-board 4GB DDR3L 1333 MHz

Storage

One mSATA, one drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional)

One mSATA, one drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional)

Watchdog Timer

Programmable 256 levels timer interval, from 1 to 255 sec

Programmable 256 levels timer interval, from 1 to 255 sec

Expansion

3 x Full-size mPCIe slot, mPCIe 2.0

1 x Full-size mPCIe slot, mPCIe 2.0

BIOS

AMI UEFI 128Mbit Flash BIOS

AMI UEFI 128Mbit Flash BIOS

Graphics Engine

Intel® HD Graphics: Gen7 with 4EU

Intel® HD Graphics: Gen7 with 4EU

Ethernet

LEDs for Power, battery, LAN (Active, Status), Tx/Rx

Intel® i210-IT GbE, 802.1Qav, IEEE1588/802.1AS, 802.3az

LED Indicators

LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD

LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD

I/O Interface

Serial Ports

2 x RS-232, DB9, 50~115.2kbps , 2 x RS-422/485, DB9, auto flow control, 50~115.2kbps

2 x RS-232, DB9, 50~115.2kbps, 2 x 232/422/485, DB9, auto flow control, 50~115.2kbps

LAN

4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

2 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

Audio

Line-In

Line-In

USB Port

4 x USB Ports (3 x USB 2.0, 1 x USB 3.0 compliant)

5 x USB Ports (4 x USB 2.0, 1 x USB 3.0 compliant)

Displays

1x VGA (2560x1600), 1x HDMI (1920x1200)

1x VGA (2560x1600), 1x HDMI (1920x1200)

Power Connector

1 x 3 Pins, Terminal Block

1 x 3 Pins, Terminal Block

Grounding Protection

Chassis Grounding

Chassis Grounding

Environment

Relative Humidity

10 ~ 95% RH @ 40°C, non-condensing

10 ~ 95% RH @ 40°C, non-condensing

Ingress Protection

IP40

IP40

Vibration Protection

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA). Operating, IEC 60068-2-64, 0.7Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA). Operating, IEC 60068-2-64, 0.7Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Shock Protection

Operating, IEC 60068-2-27, 50G, half sine, 11ms

Operating, IEC 60068-2-27, 50G, half sine, 11ms

Operating Temperature

- 20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow

- 20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow

Storage Temperature

-40 ~ 85°C ( -40 ~ 185°F)

-40 ~ 85°C ( -40 ~ 185°F)
