Part Number

UNO-2483G-434AE

UNO-2483G-474AE

UNO-2483G-4C3AE

General

Power Consumption

28W (Typical), 72W(Max)

28W (Typical), 72W(Max)

28W (Typical), 72W(Max)

Mounting

Stand, Wall, VESA (Optional)

Stand, Wall, VESA (Optional)

Stand, Wall, VESA (Optional)

Certifications

CE, FCC, UL, CCC, BSMI

CE, FCC, UL, CCC, BSMI

CE, FCC, UL, CCC, BSMI

Dimensions (W x H x D)

252 x 149 x 62 mm (9.9" x 5.9" x 2.4")

252 x 149 x 62 mm (9.9" x 5.9" x 2.4")

252 x 149 x 62 mm (9.9" x 5.9" x 2.4")

Enclosure

Aluminum Housing

Aluminum Housing

Aluminum Housing

OS Support

Microsoft® Windows 7/8

Microsoft® Windows 7/8

Microsoft® Windows 7/8

Weight (Net)

1.6kg (3.5lbs)

1.6kg (3.5lbs)

1.6kg (3.5lbs)

Power Requirement

24VDC ± 20%

24VDC ± 20%

24VDC ± 20%

Form factor

Regular Size

Regular Size

Regular Size

System Hardware

Memory

On-board 8GB DDR3L 1333/1600 MHz

On-board 8GB DDR3L 1333/1600 MHz

On-board 4GB DDR3L 1333/1600 MHz

Storage

One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional)

One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional)

One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional)

Watchdog Timer

Programmable 256 levels timer interval, from 1 to 255 sec

Programmable 256 levels timer interval, from 1 to 255 sec

Programmable 256 levels timer interval, from 1 to 255 sec

Expansion

4 x Full-size mPCIe slot, mPCIe 2.0 (3 x Full-size and 1 x half-size)

4 x Full-size mPCIe slot, mPCIe 2.0 (3 x Full-size and 1 x half-size)

4 x Full-size mPCIe slot, mPCIe 2.0 (3 x Full-size and 1 x half-size)

BIOS

AMI UEFI 128Mbit Flash BIOS

AMI UEFI 128Mbit Flash BIOS

AMI UEFI 128Mbit Flash BIOS

Processor

Intel® 4th Gen Core? i3-4010U ULT 1.7 GHz Dual Core, 3MB L2

Intel® Core? i7-4650U ULT 1.7GHz Haswell Dual Core, 4MB L2

Intel® 4th Gen Celeron® 2980U ULT 1.6 GHz Dual Core, 2MB L2

System Chip

Integrated Intel 8 Series Chipset

Integrated Intel 8 Series Chipset

Integrated Intel 8 Series Chipset

Graphics Engine

Intel® HD Graphics 5000/4400

Intel® HD Graphics 5000/4400

Intel® HD Graphics 5000/4400

LED Indicators

LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD

LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD

LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD

I/O Interface

Serial Ports

2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps

2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps

2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps

LAN

4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

Audio

Line-In, Line-Out

Line-In, Line-Out

Line-In, Line-Out

USB Port

4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant)

4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant)

4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant)

Displays

1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp

1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp

1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp

Power Connector

1 x 3 Pins, Terminal Block

1 x 3 Pins, Terminal Block

1 x 3 Pins, Terminal Block

Grounding Protection

Chassis Grounding

Chassis Grounding

Chassis Grounding

Environment

Relative Humidity

10 ~ 95% @ 40° C (non-condensing)

10 ~ 95% @ 40° C (non-condensing)

10 ~ 95% @ 40° C (non-condensing)

Ingress Protection

IP40

IP40

IP40

Vibration Protection

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA). Operating, IEC 60068-2-64, 0.7Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA). Operating, IEC 60068-2-64, 0.7Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA). Operating, IEC 60068-2-64, 0.7Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Shock Protection

Operating, IEC 60068-2-27, 50G, half sine, 11ms

Operating, IEC 60068-2-27, 50G, half sine, 11ms

Operating, IEC 60068-2-27, 50G, half sine, 11ms

Operating Temperature

-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow

-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow

-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow

Storage Temperature

-40 ~ 85°C (-40~185°F)

-40 ~ 85°C (-40~185°F)

-40 ~ 85°C (-40~185°F)
