Part Number

ARK-3510L-00A1E

Processor

CPU

Intel 3rd Gen Core i7-3610QE/Core i5-3610ME/Core i3-3120ME/Celeron 1020E

Core Number

4 / 2 / 2 / 2

Frequency

2.3 GHz/2.7 GHz/2.4 GHz/2.2GHz

L3 Cache

6 / 3 / 3 / 2 MB

Watts

45/35/35/35W

System Chipset

Intel QM77

BIOS

AMI EFI 64Mbit

Memory

Technology

DDR3/DDR3L 1600MHz

Max. Capacity

16 GB

Socket

2 x 204-pin SO-DIMM

Graphics

Chipset

Intel QM77 Integrated GFX Gen 7

Graphic Engine

DirectX11, OpenGL 3.1, and Open CL 11; Hardware decode acceleration: AVC/H.264, MPEG-2, VC-1

CRT

VGA integrated in DVI-I port

DVI-I

1920 x 1200 @ 60 Hz

HDMI

Support HDMI 1.4, 1920 x 1200 @ 60 Hz

Display port

2560 x 1600 @ 60Hz (Video only, and only support on 3rd generation processor)

Dual Display

VGA+DVI, VGA+HDMI, VGA+DP, DVI+HDMI, DVI+DP, HDMI+DP(DP not support on Celeron sku.)

Triple Display

DVI-D + HDMI + DisplayPort(not support on Celeron sku.)

Other

Watchdog Timer

255 levels timer interval, setup by software

Ethernet

LAN1

10/100/1000 Mbps Intel 82579LM GbE, support Wake On Lan

LAN2

10/100/1000 Mbps Intel I-210IT GbE, support Wake On Lan

Audio

Interface

Realtek ALC892, High Definition Audio, Line-out, Mic-in

I/O Interface

Serial Port

2 x RS-232 ports, 2 x RS-232/422/485 port with auto flow control

USB

4 x USB 3.0 ports (USB1,2,3,4); 2 x USB 2.0 ports (USB5,6)

Expansion

Mini PCIe

2 x Full-size Mini PCIe with SIM holder (Supports mSATA)

Storage

HDD

Two 2.5" SATA removable HDD Bays with maximum device height 9.5mm, SATA III, Gen 3 Support (Max. Data Transfer Rate 600 MB/s), Support SATA RAID 0, 1

Solid State Disk

1 x CFast Card

Software Support

Microsoft Windows

Windows 8 , Windows 7, XP Professional (32bit), XP Embedded (32bit)

Linux

Ubuntu 12.04

Power

Power Type

AT/ATX

Input Voltage

12 VDC, ± 10% (9 ~ 34 VDC support by request)

Power Adaptor

AC to DC, DC12V / 7A, 84 W (Optional)

Consumption

Typical 19.2/16.4/14.8/16.4W, Max. 60/36.5/30/31.8W

Mechanical

Construction

Aluminum housing

Mounting

Desk/wall-mounting

Dimensions

290 x 90 x 232 mm (11.4" x 3.54" x 9.13")

Weight

4.63kg

Environment

Operational Temperature

with extended temp peripherals: -10 ~ 60° C with 0.7m/s air flow, with HDD: 0 ~ 40° C with 0.7m/s air flow

Storage Temperature

-40 ~ 85° C

Relative Humidity

95% @ 40° C (non-condensing)

Vibration during Operation

With SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis.

Shock During Operation

With SSD: 50 G, IEC 60068-2-27, half sine, 11 ms duration

EMC

CE/FCC Class A, CCC, BSMI

Safety Certifications

CB, UL, CCC, BSMI
