Part Number

ARK-1122H-S6A1E

Processor

CPU

Intel Atom Dual Core N2600 1.6 GHz

Core Number

2

L2 Cache

1 MB

System Chipset

Intel NM10

BIOS

AMI EFI 16Mbit

Memory

Technology

DDR3 800 MHz up to 4 GB

Socket

1 x 204-pin SO-DIMM

Graphics

Chipset

Intel Atom N2600

Interface

VGA (1920 x 1200); HDMI (1920 x 1200) with lockable design (please choose the lockable HDMI cable)

Ethernet

LAN

1 x 10/100/1000 Mbps Intel 82583V GbE, supports wake on LAN

Audio

Chipset

Realtek ALC892, High Definition Audio (HD)

Interface

Line in, Line out

I/O Interface

Serial Port

1 x RS-232

USB Interface

4 x USB ports, USB2.0 Compliant

Others

Watchdog timer

255 levels timer interval, setup by software

Expansion

Mini PCIe

1 x half-size miniPCIe supports WIFI only

Storage

2.5" HDD/SSD

1 x SATA II HDD Bay

mSATA

1 x full-size Mini PCIe slot, colay with USB signal

Software Support

Microsoft Windows

Windows 7 Pro 32bit, WES7 32bit, XP Embedded (XP Embedded by project support)

Power

Input Voltage

12 VDC, ± 10%

Connector Type

Lockable DC Jack

Power Adaptor

AC to DC, DC12 V/3 A, 36 W with lockable design

Consumption

Typical 6.89 W, Max. 11.45 W

Mechanical

Construction

Aluminum housing

Mounting

Support VESA/DIN Rail/Wall mounting (Optional)

Dimensions

133.8 x 43.1 x 94.2 mm (5.27" x 1.7" x 3.71")

Environment

Operational Temperature

With standard temperature HDD/SSD/mSATA devices: 0 ~ 40° C with 0.7 m/s air flow; With extended temperature SSD/mSATA devices: -20 ~ 60° C with 0.7 m/s air flow

Storage Temperature

-40 ~ 85° C

Relative Humidity

95% @ 40° C (non-condensing)

Vibration during Operation

With SSD/mSATA: 3Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1hr/axis

Shock During Operation

With SSD/mSATA:30Grms, IEC 60068-2-27, half sine, 11ms duration

Certification

EMC

CE/FCC Class A, CCC, BSMI

Safety Certifications

CB, UL, CCC, BSMI
