Part Number

ARK-2151V-S6A1E

ARK-2151V-S9A1E

Processor

CPU

Intel Celeron 2980U Dual Core

Intel 4th Gen Core i5-4300U Dual Core

Core Number

2

2

Frequency

1.6 GHz

1.9 GHz

L3 Cache

2 MB

3 MB

BIOS

AMI EFI 128Mbit

AMI EFI 128Mbit

Memory

Technology

DDR3L 1333 MHz

DDR3L 1600 MHz

Max. Capacity

8 GB

8 GB

Socket

1 x 204-pin SO-DIMM

1 x 204-pin SO-DIMM

Graphics

Chipset

HD Graphics

GT2-4400 Graphics

Graphic Engine

DirectX11.1, OpenGL 4.0, and OpenCL 1.2,Full AVC/VC1/MPEG2 HW Decode

DirectX11.1, OpenGL 4.0, and OpenCL 1.2,Full AVC/VC1/MPEG2 HW Decode

VGA

Up to 1920 x 1200 with 60 Hz, 154 MHz pixel clock rate

Up to 1920 x 1200 with 60 Hz, 154 MHz pixel clock rate

HDMI

Lockable HDMI connector, up to 4K at 24 Hz

Lockable HDMI connector, up to 4K at 24 Hz

Audio

Main System

Realtek ALC888S, High Definition Audio (HD), Line-in, Line out, Mic-in

Realtek ALC888S, High Definition Audio (HD), Line-in, Line out, Mic-in

Ethernet

LAN1

10/100/1000 Mbps Intel I218 GbE, support Wake on LAN

10/100/1000 Mbps Intel I218 GbE, support Wake on LAN

LAN2

10/100/1000 Mbps Intel I210-IT, support Wake on LAN

10/100/1000 Mbps Intel I210-IT, support Wake on LAN

I/O Interface

Power over Ethernet, PoE

N/A

4 x 10/100 Mbps - 4ports full-load, IEEE802.3af Class 2 (7Watt) - 2ports full-load, IEEE802.3af Class 3 (15.4Watt)

Serial Port

2 x RS-232/422/485 ports w/ 3KV isolation (support auto flow control, jumper selectable)

N/A

Optional COM or CANBus

2 x DB9 connectors for RS-232/422/485 signal (Default) or CANBus 2.0A/B (Module option)

2 x DB9 connectors for RS-232/422/485 signal (Default) or CANBus 2.0A/B (Module option)

USB Interface

2 x USB 2.0 & 2 x USB3.0

2 x USB 2.0 & 2 x USB3.0

GPIO

6 x DI & 2 x DO w/ 3KV isolation Input Voltage: 0 to 30 VDC, Output Current: Max. 500 mA per channel On-state Voltage: 24 VDC nominal, open collector to 30 VDC

6 x DI & 2 x DO w/ 3KV isolation Input Voltage: 0 to 30 VDC, Output Current: Max. 500 mA per channel On-state Voltage: 24 VDC nominal, open collector to 30 VDC

Other

GPS

On board standalone GPS, support GPS, GLONASS, GALILEO and QZSS signals

On board standalone GPS, support GPS, GLONASS, GALILEO and QZSS signals

G-Sensor

On board high resolution G-Sensor, up to 13-bit resolution at ± 16g

On board high resolution G-Sensor, up to 13-bit resolution at ± 16g

Watchdog Timer

255 levels timer interval, setup by software

255 levels timer interval, setup by software

Expansion

Mini PCIe #1

Full-size Mini PCIe, support mSATA

Full-size Mini PCIe, support mSATA

Mini PCIe #2

Half-size Mini PCIe, support WLAN module

Half-size Mini PCIe, support WLAN module

Mini PCIe #3

Full-size Mini PCIe w/SIM holder, support WWAN module

Full-size Mini PCIe w/SIM holder, support WWAN module

Mini PCIe #4

Full-size Mini PCIe w/SIM holder, support WWAN module

Full-size Mini PCIe w/SIM holder, support WWAN module

Storage

2.5" Drive Bay

1 x removable 2.5" drive bay (Max 9.5mm height)

1 x removable 2.5" drive bay (Max 9.5mm height)

mSATA

Laverage MiniPCIe #1 slot

Laverage MiniPCIe #1 slot

Software Support

Microsoft Windows

WES8, WES7, Windows 8, Windows 7

WES8, WES7, Windows 8, Windows 7

Linux

Support by project

Support by project

Power

Power Type

AT/ATX

AT/ATX

Input Voltage

9 ~ 36 VDC w/isolation

9 ~ 36 VDC w/isolation

Power Ignition Management

Selectable boot-up & shut-down voltage, on/off delay time

Selectable boot-up & shut-down voltage, on/off delay time

Isolation

1.5KV Isolated

1.5KV Isolated

Mechanical

Construction

Aluminum housing, Silver

Aluminum housing, Silver

Mounting

Din-Rail mounting, Desk/wall-mounting, VESA mounting

Din-Rail mounting, Desk/wall-mounting, VESA mounting

Dimensions

264.5 x 75.1 x 133.0 mm (10.41" x 2.96" x 5.24")

264.5 x 75.1 x 133.0 mm (10.41" x 2.96" x 5.24")

Environment

Operating Temperature

With extended temperature peripherals:-20 ~ 60° C with 0.7m/s air flow,With standard temperature peripherals:0 ~ 45° C with 0.7m/s air flow

With extended temperature peripherals:-20 ~ 60° C with 0.7m/s air flow,With standard temperature peripherals:0 ~ 45° C with 0.7m/s air flow

Storage Temperature

-40 ~ 85° C (-40 ~ 185° F)

-40 ~ 85° C (-40 ~ 185° F)

Relative Humidity

95% @ 40° C (non-condensing)

95% @ 40° C (non-condensing)

Vibration/Shock

With mSATA/SSD: IEC 60721-3-5 Class 5M3

With mSATA/SSD: IEC 60721-3-5 Class 5M3

Regulation

EMC

CE/FCC Class A, CCC, BSMI

CE/FCC Class A, CCC, BSMI

Safety

UL, CCC, BSMI, E-Mark (E13)

UL, CCC, BSMI, E-Mark (E13)

In-Vehicle Power

ISO7637-2 Lev.4

ISO7637-2 Lev.4
