Part Number

ARK-2121S-S9A1E

Processor

CPU

Intel Atom E3845 QC SoC

Core Number

4

Frequency

1.91 GHz

L2 Cache

2 MB

BIOS

AMI EFI 64 Mbit

Memory

Technology

DDR3L 1333 MHz

Max. Capacity

8 GB

Socket

1 x 204 pin SO-DIMM

Graphics

Chipset

Intel Gen7 Graphics

Graphic Engine

DirectX11, OpenGL3.2, OpenCL1.1 Full HW acceleration, decode: H.264, MPEG2/4, VC-1, WMV9. Encode: H.264, MPEG2

VGA

Up to 2560 x 1600 @ 60Hz

HDMI

Lockable HDMI connector, up to 1080p

Audio

Main System

Realtek ALC888S, High Definition Audio (HD), Line-in, Line out, Mic-in

Ethernet

LAN1

10/100/1000 Mbps Intel I210-IT GbE, support Wake on LAN

LAN2

10/100/1000 Mbps Intel I210-IT GbE, support Wake on LAN

I/O Interface

Power over Ethernet, PoE

4 x 10/100 Mbps - 4ports full-load, IEEE802.3af Class 2 (7Watt) - 2ports full-load, IEEE802.3af Class 3 (15.4Watt)

Serial Port

2 x RS-232/422/485 ports (support auto flow control, BIOS selectable)

GPIO

6 x DI & 2 x DO w/ 3KV isolation Input Voltage: 0 to 30 VDC, Output Current: Max. 500 mA per channel On-state Voltage: 24 VDC nominal, open collector to 30 VDC

USB

3 x USB 2.0 & 1 x USB3.0

Other

Watchdog Timer

255 levels timer interval, setup by software

Expansion

Mini PCIe #1

Full-size Mini PCIe, support mSATA

Mini PCIe #4

Full-size Mini PCIe w/SIM holder, support WWAN module

Mini PCIe #3

Full-size Mini PCIe w/SIM holder, support WWAN module

Mini PCIe #2

Full-size Mini PCIe, support WLAN module

Storage

2.5" Drive Bay

1x Hot-swappable 2.5" drive bay (Max 9.5mm height)

mSATA

Laverage MiniPCIe #1 slot

Software Support

Microsoft Windows

WES8, WES7, Windows 8, Windows 7

Linux

Support by project

Power

Power Type

AT / ATX

Input Voltage

9 ~ 36 VDC w/isolation

Isolation

1.5KV Isolated

Mechanical

Mounting

Din-Rail mounting, Desk/wall-mounting, VESA mounting

Construction

Aluminum housing, Silver

Dimensions

264.5 x 69.2 x 133.0 mm (10.41" x 2.72" x 5.24")

Environment

Operating Temperature

With extended temperature peripherals: -30~60° C with 0.7m/s air flow With standard temperature peripherals: 0 ~ 45° C with 0.7m/s air flow

Storage Temperature

-40 ~ 85° C (-40 ~ 185° F)

Relative Humidity

95% @ 40° C (non-condensing)

Vibration during Operation

With mSATA/SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

Shock During Operation

With mSATA/SSD: 30G, IEC 60068-2-27, half sine, 11 ms duration

Regulation

EMC

CE/FCC Class A, CCC, BSMI

Safety

CB, UL, CCC, BSMI
