Part Number

AIMB-580QG2-00A1E

AIMB-580QG2-00A1E

Form Factor

Form Factor

Micro ATX

Micro ATX

Processor

CPU

Intel i7-860 / i5-750 / i5-660 / i3-540/ Pentium G6950

Intel Xeon 3450 / Core i5-660 / i3-540/ Pentium G6950

CPU TDP

95W / 73W

95W / 65W

Frequency

2.66GHz ~ 3.3 GHz

2.66GHz ~ 3.3 GHz

Core Number

2/4

2/4

L3 Cache

3 ~ 8MB

3 ~ 8MB

BIOS

AMI EFI 64Mbit

AMI EFI 64Mbit

Chipset

Intel Q57 PCH

Intel 3450 PCH

Memory

Technology

DDR3 800/1066/1333 MHz

DDR3 800/1066/1333 MHz

Max. Capacity

16 GB

16 GB

ECC Support

No

Yes

Socket

4 x 240-pin DIMM

4 x 240-pin DIMM

Display

Controller

Intel HD Graphics

Intel HD Graphics

Graphic Engine

DirectX 10 and Open GL 2.1 supported

DirectX 10 and Open GL 2.1 supported

Graphic Memory

1GB maximum shared memory with 2GB and above system memory installed

1GB maximum shared memory with 2GB and above system memory installed

VGA

Up to 2048 x 1563 @ 60Hz

Up to 2048 x 1563 @ 60Hz

DDI (HDMI/DVI/DisplayPort)

DVI: 1920 x 1200 @ 60Hz

DVI: 1920 x 1200 @ 60Hz

Multiple Display

Dual

Dual

Expansion

PCI Express x 16

1

1

PCI Express x 4

1

1

PCI

2

2

LPC

1

1

Ethernet

Controller

GbE1: Intel 82578DM GbE2: Intel 82583V

GbE1: Intel 82578DM GbE2: Intel 82583V

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Connector

RJ45 x 2

RJ45 x 2

Audio

Audio Interface

HD Audio

HD Audio

CODEC

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Connector

2 (Line out, Mic-in)

2 (Line out, Mic-in)

Watchdog Timer

WatchDog Timer

Yes

Yes

Storage

SATA

6 x SATAII (Max. Data Transfer Rate 300 MB/s)

6 x SATAII (Max. Data Transfer Rate 300 MB/s)

RAID

Software RAID 0, 1, 5, 10

Software RAID 0, 1, 5, 10

I/O

USB2.0

10

10

LPT

1

1

COM Port

4 ( 3 x RS232, 1 x RS232/ 422/ 485)

4 ( 3 x RS232, 1 x RS232/ 422/ 485)

Keypad

1

1

TPM

Optional

Optional

Smart Fan

3

3

Power

Power Type

ATX

ATX

Connector

ATX24P

Power Consumption (Idle)

1.82A @ 5V / 0.64A @ 3.3V / 1.48A @ 12V / 0A @ 5Vsb / 0A @ -12V

1.85A @ 5V / 0.91A @ 3.3V / 2.84A @ 12V / 0.06A @ 5Vsb / 0.12A @ -12V

Power Consumption (Full Load)

1.8A @ 5V / 0.67A @ 3.3V / 3.55A @ 12V / 0.01A @ 5Vsb / 0A @ -12V

2.8A @ 5V / 0.99A @ 3.3V / 5.14A @ 12V / 0.01A @ 5Vsb / 0.13A @ -12V

Battery

Lithium 3 V / 200 mAh

Lithium 3 V / 200 mAh

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

Non-Operational Temperature

’-20 ~ 70° C (-4 ~ 158F) and 60° C @ 95% RH Non-Condensing

-20 ~ 70° C (-4 ~ 158F) and 60° C @ 95% RH Non-Condensing

Vibration Resistance

3.5 Grm (Non-Operation Mode)

3.5 Grm (Non-Operation Mode)

Physical

Dimension (mm)

Weight 244 x 244 mm

Weight 244 x 244 mm

Weight

1.2 kg (2.64 lb), weight of total package

1.2 kg (2.64 lb), weight of total package

Operating System

Microsoft Windows

Yes

Yes

Linux

Yes

Yes

SUSIAccess

Yes

Yes

Certification

EMC

CE, FCC

CE, FCC
