Part Number

PCM-3910-00A1E

PCM-3910Z-00A1E

Form Factor

Form Factor

PC/104-Plus

PC/104-Plus

Expansion

PC/104-Plus

1

1

Power

Power Supply Voltage

Input: 10 V to 24 VDC ±5% Output: 5 V output 10.0 A 12 V output 2.0 A -5 V output 0.4 A (optional) -12 V output 0.4 A

Input: 10 V to 24 VDC ±5% Output: 5 V output 10.0 A 12 V output 2.0 A -5 V output 0.4 A (optional) -12 V output 0.4 A

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

-20° C ~ 80° C

Physical

Dimension (mm)

96 x 90 mm (3.8" x 3.5")

96 x 90 mm (3.8" x 3.5")

Weight

0.084 kg (0.185 lb)

0.084 kg (0.185 lb)
