Part Number

AIMB-230G2-U0A1E

AIMB-230G2-U3A1E

AIMB-230G2-U5A1E

Expansion

Slots

Full-size Mini-PCIe, Half-size Mini-PCIe

Full-size Mini-PCIe, Half-size Mini-PCIe

Full-size Mini-PCIe, Half-size Mini-PCIe

Slot Type

1 x Full-size (Supports mSATA) 1 x Half-size

1 x Full-size (Supports mSATA) 1 x Half-size

1 x Full-size (Supports mSATA) 1 x Half-size

Processor

CPU

Intel Celeron 2980U

Intel® Core? i3-4010U

Intel Core i5-4300U

CPU TDP

15 W

15 W

15 W

Frequency

1.8 GHz / 1.7 GHz

1.8 GHz / 1.7 GHz

1.8 GHz / 1.7 GHz

Core Number

2/4

2/4

2/4

L3 Cache

2 MB

3MB/2MB

3 MB

BIOS

AMI EFI 128Mbit

AMI EFI 128Mbit

AMI EFI 128Mbit

Chipset

Wildcat Point-LP

Wildcat Point-LP

Wildcat Point-LP

Display

Video Interface

HDMI+LVDS (eDP), HDMI+DP++, LVDS (eDP)+DP++

HDMI+LVDS (eDP), HDMI+DP++, LVDS (eDP)+DP++

HDMI+LVDS (eDP), HDMI+DP++, LVDS (eDP)+DP++

LCD (TTL/LVDS/eDP)

LVDS: Dual channel 24-bit LVDS, up to 1920 x 1080

LVDS: Dual channel 24-bit LVDS, up to 1920 x 1080

LVDS: Dual channel 24-bit LVDS, up to 1920 x 1080

Controller

Intel Processor Integrated

Intel Processor Integrated

Intel Processor Integrated

Graphic Engine

DirectX 11.1, OpenGL 4.0, OpenCL 1.3, Full AVC, VC1, MPEG2 H/W encoder

DirectX 11.1, OpenGL 4.0, OpenCL 1.3, Full AVC, VC1, MPEG2 H/W encoder

DirectX 11.1, OpenGL 4.0, OpenCL 1.3, Full AVC, VC1, MPEG2 H/W encoder

Graphic Memory

Share with system memory,2 GB and above

Share with system memory,2 GB and above

Share with system memory,2 GB and above

DDI (HDMI/DVI/DisplayPort)

HDMI : 1920 x 1080 @ 60Hz

HDMI : 1920 x 1080 @ 60Hz

HDMI : 1920 x 1080 @ 60Hz

Multiple Display

Dual/ Triple

Dual/ Triple

Dual/ Triple

Form Factor

Form Factor

mini ITX

mini ITX

mini ITX

Memory

Technology

DDR3L 1333 MHz

DDR3L 1333 MHz

DDR3L 1333 MHz

Max. Capacity

16 GB

16 GB

16 GB

Socket

2x 204 PIN SODIMM

2x 204 PIN SODIMM

2x 204 PIN SODIMM

Ethernet

Controller

GbE1: Realtek RTL8111E; GbE2: Realtek RTL8111E

GbE1: Realtek RTL8111E; GbE2: Realtek RTL8111E

GbE1: Realtek RTL8111E; GbE2: Realtek RTL8111E

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Connector

RJ45 x 2

RJ45 x 2

RJ45 x 2

Audio

Audio Interface

HD Audio

HD Audio

HD Audio

CODEC

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Connector

2 (Line out, Mic In)

2 (Line out, Mic In)

2 (Line out, Mic In)

Watchdog Timer

WatchDog Timer

Yes

Yes

Yes

Storage

SATA

3 x SATA III (Max. Data Transfer Rate 600 MB/s)

3 x SATA III (Max. Data Transfer Rate 600 MB/s)

3 x SATA III (Max. Data Transfer Rate 600 MB/s)

mSATA

miniPCIe co-lay mSATA

miniPCIe co-lay mSATA

miniPCIe co-lay mSATA

CFast

0

0

0

I/O

USB3.0

4

4

4

USB2.0

2

2

2

COM Port

2 ( 1 x RS232, 1 x RS232/ 422/ 485)

2 ( 1 x RS232, 1 x RS232/ 422/ 485)

2 ( 1 x RS232, 1 x RS232/ 422/ 485)

Smart Fan

2

2

2

Power

Power Type

ATX, AT

ATX, AT

ATX, AT

Connector

DC 12V Jack/ 4-pin with ATX12V

DC 12V Jack/ 4-pin with ATX12V

DC 12V Jack/ 4-pin with ATX12V

Power Adaptor

Yes

Yes

Yes

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

Vibration Resistance

1 Grm (OP)

1 Grm (OP)

1 Grm (OP)

Physical

Dimension (mm)

170 x 170 mm

170 x 170 mm

170 x 170 mm

Weight

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

Construction

Thermal moudle or CPU cooler

Thermal moudle or CPU cooler

Thermal moudle or CPU cooler

Operating System

Microsoft Windows

Yes

Yes

Yes

Linux

Yes

Yes

Yes

SUSIAccess

Yes

Yes

Yes

iManager

Yes

Yes

Yes

Certification

EMC

CE, FCC

CE, FCC

CE, FCC

Safety Certifications

CCC/BSMI

CCC/BSMI

CCC/BSMI
