Part Number

AIMB-203G2-00A1E

AIMB-203L-00A1E

Processor

CPU

Intel® Core? i7/i5/i3/Pentium

Intel® Core? i7/i5/i3/Pentium

CPU TDP

95W/65W/45W/35W

95W/65W/45W/35W

Frequency

2.3 ~ 3.5 GHz

2.3 ~ 3.5 GHz

Core Number

4/2

4/2

L3 Cache

3 ~ 8MB

3 ~ 8MB

BIOS

AMI EFI 64 Mbit

AMI EFI 64 Mbit

Chipset

Intel H81

Intel H81

Memory

Technology

DDR3 1333 / 1600 MHz

DDR3 1333 / 1600 MHz

Max. Capacity

16 GB

16 GB

Socket

2 x 204-pin SODIMM

2 x 204-pin SODIMM

Display

Controller

Integrated Gfx Gen. 7.5

Integrated Gfx Gen. 7.5

Graphic Engine

DirectX11.1, Open GL 4.0

DirectX11.1, Open GL 4.0

Graphic Memory

Share with system memory up to 2 GB

Share with system memory up to 2 GB

DDI (HDMI/DVI/DisplayPort)

Display port 1.2 supports up to 3840 x 2160; DVI-D supports up to 1920 x 1200

DVI-D supports up to 1920 x 1200

VGA

Up to 1920 x 1200

Up to 1920 x 1200

LCD (TTL/LVDS/eDP)

LVDS: dual channel 48-bit

0

Multiple Display

Dual

Dual

Expansion

PCI Express x 16

1

1

Mini PCIe

2 (one full size supports mSATA and one half size with SIM card holder)

1 full size MiniPCIe suppors mSATA

Ethernet

Controller

GbE LAN1: Realtek RTL8111E, GbE LAN2: Realtek RTL8111E

GbE1:Realtek RTL8111E

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Connector

RJ45 x 2

RJ45 x 1

Audio

Audio Interface

HD Audio

HD Audio

CODEC

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Connector

3 (Mic-in, Line-out, Line-in)

3 (Mic-in, Line-out, Line-in)

Watchdog Timer

WatchDog Timer

Yes

Yes

Storage

CFast

0

0

SATA

2 SATA 3.0 & 1 SATA 2.0

2 SATA 3.0 & 1 SATA 2.0

I/O

USB2.0

6

6

COM Port

9 (8 x RS-232; 1 x RS-232/422/485)

9 (8 x RS-232; 1 x RS-232/422/485)

GPIO

8-bit

8-bit

TPM

Optional

0

USB3.0

2

2

Parallel port

1

0

PS/2

2 ( 1 x keyboard & 1 x mouse)

2 ( 1 x keyboard & 1 x mouse)

Power

Connector

ATX20P

ATX20P

Power Type

ATX

ATX

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

Non-Operational Temperature

-40~ 85° C

-40~ 85° C

Vibration Resistance

3.5 Grms (non OP)

3.5 Grms (non OP)

Physical

Dimension (mm)

170 x 170 mm

170 x 170 mm

Weight

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

Construction

with CPU cooler design

with CPU cooler design

Operating System

Microsoft Windows

Yes

Yes

Linux

Yes

Yes

SUSIAccess

SUSIAccess Pro Built In

0

Certification

EMC

CE, FCC Class B

CE, FCC Class B
