Part Number

AIMB-232G2-U0A1E

AIMB-232G2-U0B1E

AIMB-232G2-U3A1E

Expansion

Slots

2 Full-size Mini PCIe

2 Full-size Mini PCIe

2 Full-size Mini PCIe

Slot Type

2 F/S mini-PCIe (support mSATA & SIM card holder)

2 F/S mini-PCIe (support mSATA & SIM card holder)

2 F/S mini-PCIe (support mSATA & SIM card holder)

Processor

CPU

Intel Celeron 3955U

-

Intel Core i3 6100U

CPU TDP

15 W

15 W

15 W

BIOS

AMMI uEFI 16 Mbit

AMMI uEFI 16 Mbit

AMMI uEFI 16 Mbit

Core Number

2

2

2

Chipset

Intel Sunris Ponit LP

Intel Sunris Ponit LP

Intel Sunris Ponit LP

Frequency

2.0 GHz

2.0 GHz

2.3 GHz

L3 Cache

2 MB

2 MB

3 MB

Display

Video Interface

DP, HDMI, LVDS(eDP), trupple display ports

DP, HDMI, LVDS(eDP), trupple display ports

DP, HDMI, LVDS(eDP), trupple display ports

LCD (TTL/LVDS/eDP)

LVDS 48-bit, up to 1920 x 1200 at 60 Hz

LVDS 48-bit, up to 1920 x 1200 at 60 Hz

LVDS 48-bit, up to 1920 x 1200 at 60 Hz

Controller

Intel Processor Integrated

Intel Processor Integrated

Intel Processor Integrated

Graphic Engine

DirectX 11.2, OpenGL 5.0, OpenCL 2.1

DirectX 11.2, OpenGL 5.0, OpenCL 2.1

DirectX 11.2, OpenGL 5.0, OpenCL 2.1

DDI (HDMI/DVI/DisplayPort)

HDMI: 4096x2160@60Hz / DP++: 4096x2304@60Hz

HDMI: 4096x2160@60Hz / DP++: 4096x2304@60Hz

HDMI: 4096x2160@60Hz / DP++: 4096x2304@60Hz

Graphic Memory

Shared system memory

Shared system memory

Shared system memory

Multiple Display

Dual/ Triple

Dual/ Triple

Dual/ Triple

Form Factor

Form Factor

mini ITX

mini ITX

mini ITX

Memory

Max. Capacity

32GB (16GB per SODIMM)

32GB (16GB per SODIMM)

32GB (16GB per SODIMM)

Technology

DDR4 SO-DIMM up to 2400MHz

DDR4 SO-DIMM up to 2400MHz

DDR4 SO-DIMM up to 2400MHz

Socket

2 x 260 Pin DDR4 SO-DIMM

2 x 260 Pin DDR4 SO-DIMM

2 x 260 Pin DDR4 SO-DIMM

Ethernet

Controller

GbE1: Intel I219LM, GbE2: Intel I211

GbE1: Intel I219LM, GbE2: Intel I211

GbE1: Intel I219LM, GbE2: Intel I211

Connector

RJ45 x 2

RJ45 x 2

RJ45 x 2

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Audio

Audio Interface

HD Audio

HD Audio

HD Audio

CODEC

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Connector

2 (Line out, Mic In)

2 (Line out, Mic In)

2 (Line out, Mic In)

Watchdog Timer

WatchDog Timer

Yes

Yes

Yes

Storage

mSATA

miniPCIe co-lay mSATA

miniPCIe co-lay mSATA

miniPCIe co-lay mSATA

SATA

2 x SATA3 (max data transfer rate 6.0 Gb/s)

2 x SATA3 (max data transfer rate 6.0 Gb/s)

2 x SATA3 (max data transfer rate 6.0 Gb/s)

I/O

USB3.0

4

4

6

USB2.0

4

4

2

COM Port

2 ( 2 x RS-232 )

2 ( 2 x RS-232 )

2 ( 2 x RS-232 )

Smart Fan

2

2

2

Power

Power Type

ATX, AT

ATX, AT

ATX, AT

Connector

DC 12V Jack/ 4-pin with ATX12V

DC 12V Jack/ 4-pin with ATX12V

DC 12V Jack/ 4-pin with ATX12V

Power Adaptor

Yes

Yes

Yes

Environment

Operational Temperature

0 ~ 60° C with air flow 0.7m/s (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C with air flow 0.7m/s (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C with air flow 0.7m/s (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

Vibration Resistance

1 Grm (OP)

1 Grm (OP)

1 Grm (OP)

Physical

Dimension (mm)

170 x 170 mm

170 x 170 mm

170 x 170 mm

Construction

with fanless design

with fanless design

with fanless design

Weight

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

Operating System

Microsoft Windows

Yes

Yes

Yes

Linux

Yes

Yes

Yes

SUSIAccess

Yes

Yes

Yes

Certification

EMC

CE/FCC

CE/FCC

CE/FCC
