Part Number

AIMB-275G2-00A1E

AIMB-275L-00A1E

AIMB-275VG-00A1E

Processor

CPU

6th Gen. Intel Core i7/i5/i3 Series Prosssor

6th Gen. Intel Core i7/i5/i3 Series Prosssor

6th Gen. Intel Core i7/i5/i3 Series Prosssor

CPU TDP

65W / 35W

65W / 35W

65W / 35W

Frequency

2.3G~3.4GHz

2.3G~3.4GHz

2.3G~3.4GHz

Core Number

4/2

4/2

4/2

L3 Cache

2 ~ 8MB

2 ~ 8MB

2 ~ 8MB

BIOS

AMI UEFI 128 Mbit

AMI UEFI 128 Mbit

AMI UEFI 128 Mbit

Chipset

Intel Q170

Intel H110

Intel Q170

Memory

Technology

DDR4 2133MHz SO-DIMM

DDR4 2133MHz SO-DIMM

DDR4 2133MHz SO-DIMM

Max. Capacity

32GB (up to 16GB per SO-DIMM)

32GB (up to 16GB per SO-DIMM)

32GB (up to 16GB per SO-DIMM)

Socket

2 x 260 Pin DDR4 SO-DIMM

2 x 260 Pin DDR4 SO-DIMM

2 x 260 Pin DDR4 SO-DIMM

Display

Controller

Intel HD Graphics

Intel HD Graphics

Intel HD Graphics

Graphic Engine

DirectX11.1, Open GL 4.0

DirectX11.1, Open GL 4.0

DirectX11.1, Open GL 4.0

Graphic Memory

Share with system memory up to 2 GB

Share with system memory up to 2 GB

Share with system memory up to 2 GB

LVDS

48-bit LVDS up to 1920 x 1200 at 60Hz

48-bit LVDS up to 1920 x 1200 at 60Hz

48-bit LVDS up to 1920 x 1200 at 60Hz

Video Interface

VGA,LVDS,HDMI,eDP,DP, support triple display

DP/HDMI/VGA/ support dual display

VGA,LVDS,HDMI,eDP,DP, support triple display

DDI (HDMI/DVI/DisplayPort)

HDMI: upto 4096x2160@60Hz ; DP:3840x2160@60Hz

HDMI: Up to 4096 x 2304 @ 24 Hz / 2560 x 1600 @ 60 Hz. DP: Up to 3840 x 2160 @ 60 Hz.

HDMI: Up to 4096 x 2304 @ 24 Hz / 2560 x 1600 @ 60 Hz. DP: Up to 3840 x 2160 @ 60 Hz.

Multiple Display

Triple

Dual

Triple

Expansion

PCI Express x 16

1

1

1

Slot Type

1 (F/S, mSATA support);1 M.2 (B-key)

1 x Full-size

1 x Full-size

Slots

PCIex16,mini-PCIe, M.2

PCIe x16, Mini-PCIe

PCIe x16, Mini-PCIe

Ethernet

Controller

LAN1: Intel i219LM / LAN2: Intel i211AT

Intel i219LM

Intel i219LM

Connector

RJ45 x 2

RJ45 x 1

RJ45 x 1

Audio

Audio Interface

HD Audio

HD Audio

HD Audio

CODEC

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Connector

3 (Mic-in, Line-out, Line-in)

3 (Mic-in, Line-out, Line-in)

3 (Mic-in, Line-out, Line-in)

Watchdog Timer

WatchDog Timer

Yes

Yes

Yes

Storage

CFast

0

0

0

I/O

USB3.0

6

6

6

GPIO

8-bit

8-bit

8-bit

COM Port

2 ( 1 x RS232, 1 x RS232/ 422/ 485)

2 ( 1 x RS232, 1 x RS232/ 422/ 485)

2 ( 1 x RS232, 1 x RS232/ 422/ 485)

USB2.0

4

4

4

TPM

Optional

Optional

Optional

Power

Power Type

12-24 DC input

12-24 DC input

12-24 DC input

Connector

1x4pin power connector

1x4pin power connector

1x4pin power connector

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

Non-Operational Temperature

-40~ 85° C

-40~ 85° C

-40~ 85° C

Vibration Resistance

3.5 Grms (non OP)

3.5 Grms (non OP)

3.5 Grms (non OP)

Physical

Dimension (mm)

170x 170 mm (without heatsink)

170x 170 mm (without heatsink)

170x 170 mm (without heatsink)

Weight

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

Construction

with CPU cooler design

with CPU cooler design

with CPU cooler design

Operating System

Microsoft Windows

Yes

Yes

Yes

Linux

Yes

Yes

Yes

SUSIAccess

Yes

Yes

Yes

Certification

EMC

CE, FCC

CE, FCC

CE, FCC
