Part Number

AIMB-276G2-00A1E

AIMB-276G2-01A1E

Processor

CPU

Intel® 8th Gen Core? i processor/Pentium/Celeron (LGA1151)

Intel® 8th Gen Core? i processor/Pentium/Celeron (LGA1151)

CPU TDP

65W/54W/35W

65W/54W/35W

Frequency

2.1~3.7 GHz

2.1~3.7 GHz

Core Number

2/4/6

37352

L3 Cache

2 ~ 8MB

2 ~ 8MB

BIOS

AMI EFI 128Mbit

AMI EFI 128Mbit

Chipset

Intel Q370

Intel Q370

Memory

Technology

DDR4 2666MHz SO-DIMM

DDR4 2666MHz SO-DIMM

Max. Capacity

32GB (up to 16GB per SO-DIMM)

32GB (up to 16GB per SO-DIMM)

Socket

2 x 260 Pin DDR4 SO-DIMM

2 x 260 Pin DDR4 SO-DIMM

Display

Graphic Engine

Intel HD Graphic

Intel HD Graphic

DDI (HDMI/DVI/DisplayPort)

HDMI:max 4096x2160 @ 24 Hz; DP:4096x2304 @ 60Hz

HDMI:max 4096x2160 @ 24 Hz; DP:4096x2304 @ 60Hz

LVDS

Dual channel 24-bit LVDS, max resolution up to 1920 x 1200 with 60Hz

Dual channel 24-bit LVDS, max resolution up to 1920 x 1200 with 60Hz

Multiple Display

Triple

Triple

Video Interface

DP+DP+LVDS(or eDP), DP+DP+HDMI, DP+HDMI+LVDS(or eDP)

DP+DP+LVDS(or eDP), DP+DP+HDMI, DP+HDMI+LVDS(or eDP)

Expansion

PCI Express x 16

1

1

Slot Type

1 x B key (Type: 2242, 3042mm) + 1 x E key (Type: 2230)

1 x B key (Type: 2242, 3042mm) + 1 x E key (Type: 2230)

Slots

1 x M.2 B key + 1 x M.2 E key, 1 x PCIex16

1 x M.2 B key + 1 x M.2 E key, 1 x PCIex16

Ethernet

Controller

GbE1: Intel I219LM, GbE2: Intel I211

GbE1: Intel I219LM, GbE2: Intel I211

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Connector

RJ45 x 2

RJ45 x 2

Audio

Audio Interface

HD Audio

HD Audio

CODEC

Realtek ALC888S

Realtek ALC888S

Connector

3 (Line-in, Line out, Mic-in)

3 (Line-in, Line out, Mic-in)

Storage

SATA

3 x SATAIII

3 x SATAIII

Watchdog Timer

WatchDog Timer

Yes

Yes

I/O

COM Port

2 (1xRS-232, 1xRS-232/422/485)

2 (1xRS-232, 1xRS-232/422/485)

USB2.0

4

4

GPIO

8-bit GPIO

8-bit GPIO

TPM

Optional

Optional

USB3.0

10

10

Power

Connector

4pin terminal block

DC 12V Jack/ 4-pin with ATX12V

Power Type

12-24 DC input

Single 12V DC power input

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

Non-Operational Temperature

-40~ 85° C

-40~ 85° C

Vibration Resistance

3.5 Grms (non OP)

3.5 Grms (non OP)

Physical

Dimension (mm)

170x 170 mm (without heatsink)

170x 170 mm (without heatsink)

Construction

with CPU cooler design

with CPU cooler design

Weight

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

Operating System

Microsoft Windows

Windows 10 (64-bit)

Windows 10 (64-bit)

Linux

Yes

Yes

SUSIAccess

Yes

Yes

Certification

EMC

CE/FCC Class B

CE/FCC Class B
